Parker XV500CS-16 Ball Valve 1 Inch Fnpt 2000 Psi

Product Description

The PARKER XV500CS-16 is a standard 2-piece manual ball valve designed for industrial and mechanical piping systems requiring reliable on/off flow control. Built with a carbon steel body and carbon steel trim, it handles working pressures up to 2000 psi. The valve uses a lever handle for quick quarter-turn operation and features reinforced polytetrafluoroethylene (PTFE) seats and seals for chemical resistance and long service life. At 2.28 pounds, it is a compact, full-weight valve suited for high-pressure service lines. Plumbers, pipefitters, and mechanical contractors install this valve in commercial and industrial applications.

The XV500CS-16 is rated for 1 inch FNPT x FNPT end connections, making it compatible with standard female threaded pipe installations. Its 2-piece body construction simplifies field servicing and allows in-line disassembly without removing the valve from the line. This valve is appropriate for use in hydraulic, pneumatic, oil, gas, and compatible fluid systems where a durable carbon steel shutoff valve is required. It is well suited for mechanical rooms, equipment isolation, and process piping in both commercial and light industrial environments.

Key Features

• 2-piece carbon steel body rated to 2000 psi maximum working pressure
• 1 inch FNPT x FNPT end connections for standard threaded pipe installations
• Lever handle provides fast quarter-turn manual actuation
• Reinforced PTFE seats and seals resist chemical degradation and maintain tight shutoff
• 2-piece body design allows in-line servicing without full line removal
• Compliant with California Proposition 65 standards

Compatibility

Designed as an OEM-style replacement or new-installation standard ball valve for 1 inch threaded pipe systems using FNPT x FNPT connections in high-pressure industrial and mechanical piping applications.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable mechanical and plumbing codes such as the IPC or ASME B31.3. Depressurize and isolate the pipe system fully before installing or servicing this valve. Apply appropriate thread sealant to male pipe threads before making up connections. Do not exceed the rated working pressure of 2000 psi for the system or valve.
