Parker W68PLP-12M-4R Push-to-connect Male Connector

Product Description

The PARKER W68PLP-12M-4R is a straight push-to-connect male connector fitting designed for tube-to-male threaded connections in fluid and pneumatic systems. It accepts a 12mm outside diameter tube on the push-in end and features a BSPT male thread on the opposite end. Constructed from nickel-plated brass, the fitting is rated to 300 psi maximum working pressure and handles temperatures from 0 degrees F to 200 degrees F. The silver body with yellow release button makes it easy to identify and disconnect tubing during service. This fitting is installed by HVAC technicians, plumbers, and industrial maintenance professionals working on compressed air, pneumatic control, or fluid transfer lines.

This fitting is suited for residential and light commercial applications where quick, tool-free tube connections to male-threaded ports are required. Typical install scenarios include pneumatic control panels, fluid distribution manifolds, and HVAC equipment with BSPT-ported components. The push-to-connect design allows tubing to be inserted and locked in place without ferrules, compression nuts, or soldering. The yellow release button enables fast, clean tube removal during maintenance or system reconfiguration without special tools.

Key Features

• Push-to-connect design accepts 12mm OD tubing without ferrules or compression hardware
• Nickel-plated brass construction resists corrosion and suits both pneumatic and fluid service
• Rated to 300 psi maximum working pressure
• BSPT male thread on outlet end for compatibility with British Standard Parallel and Taper ported equipment
• Yellow release button allows tool-free tube removal during service
• UL94 V-0 flame resistance rating and silicone-free grease for clean, low-contamination applications

Compatibility

Designed as an OEM-style push-to-connect fitting for systems utilizing 12mm OD tubing and BSPT male-threaded ports in pneumatic or fluid transfer applications.

Installation Notes

Installation requires no special tools for the push-to-connect end — ensure tubing is cut squarely and deburred before insertion to achieve a proper seal. Verify the receiving port thread standard is BSPT before installing; BSPT and NPT threads are not interchangeable and cross-threading will damage the fitting. Depressurize and de-energize the system completely before servicing any push-to-connect fitting. Consult applicable codes and equipment manufacturer documentation for torque guidance on the threaded male end.
