Parker W172PLP-3-2 Male Branch Tee 3/16in Od 1/8in Nptf

Product Description

The PARKER W172PLP-3-2 is a push-to-connect male branch tee tube fitting designed for fast, tool-free tubing connections in pneumatic and fluid systems. Built from nickel-plated brass, it connects two inline tube runs to a male NPTF threaded port, forming a tee configuration without soldering or compression ferrules. It accepts 3/16 inch OD tubing on the tube ports and features a 1/8 inch NPTF male thread on the branch port. The fitting is rated to 300 psi maximum working pressure and handles temperatures from 0 degrees F to 200 degrees F. The release button is made from black flame-resistant material compliant with the UL94 V-0 standard. Licensed HVAC technicians, plumbers, and instrumentation technicians install this fitting in both residential and light commercial applications.

This fitting is suited for pneumatic control lines, instrumentation tubing, low-pressure fluid circuits, and HVAC control system tubing where a quick, reliable branch connection to a male-threaded port is needed. The push-to-connect design allows field installation and tubing removal without special tools, making it practical for service and retrofit work in tight panel spaces or equipment enclosures. It is appropriate for use with compatible semi-rigid or nylon tubing at 3/16 inch OD.

Key Features

• Push-to-connect design accepts 3/16 inch OD tubing with no ferrules or compression tools required
• 1/8 inch NPTF male branch port provides a reliable tapered-thread seal
• Nickel-plated brass body offers corrosion resistance for pneumatic and fluid service
• Rated to 300 psi maximum working pressure
• Operating temperature range of 0 degrees F to 200 degrees F
• UL94 V-0 flame-resistant release button material for safety-sensitive installations
• Nitrile O-ring for dependable tube retention and sealing

Compatibility

Designed as an OEM-style push-to-connect branch tee for systems using 3/16 inch OD semi-rigid or nylon tubing with a 1/8 inch NPTF male threaded port; connection type is Tube x MNPT x Tube x Male.

Installation Notes

Installation is performed by licensed HVAC technicians, plumbers, or instrumentation technicians. Always depressurize and isolate the system before disconnecting or installing any push-to-connect fitting. Ensure tubing ends are cut squarely and deburred before insertion to achieve a proper seal. Verify that the mating threaded port uses NPTF taper thread to match this fitting; do not force incompatible thread forms.
