Parker W171PLP-8M-6R Swivel Male Run Tee 8mm 300 Psi

Product Description

The PARKER W171PLP-8M-6R is a push-to-connect swivel male run tee fitting designed for tube-to-tube-to-male plumbing and pneumatic connections. Constructed from nickel-plated brass with a silicone-free grease internal seal, it accepts 8mm outside-diameter tubing on the push-to-connect ports and features a BSPT male thread on the branch outlet. The fitting is rated to 300 psi maximum working pressure and handles temperatures from 0 degrees F to 200 degrees F. The yellow release button allows fast, tool-free tube insertion and removal. Licensed HVAC technicians, plumbers, and pneumatic system installers use this fitting in both residential and light commercial applications.

This fitting is suited for pneumatic control lines, compressed air distribution, and fluid handling systems where a swivel male run tee configuration is required. The 8mm OD tube connection pairs with BSPT threaded ports common in European and international equipment. The swivel feature on the male thread simplifies alignment during installation without requiring the body to rotate. Typical use cases include instrument air lines, HVAC pneumatic controls, and process fluid circuits operating within the rated temperature and pressure envelope.

Key Features

• Push-to-connect design for tool-free tube insertion and release via yellow button
• Nickel-plated brass construction for corrosion resistance in air and fluid service
• 300 psi maximum working pressure rating
• Operating temperature range of 0 degrees F to 200 degrees F
• BSPT male thread on branch outlet with swivel capability for easy alignment
• Silicone-free internal grease — compatible with systems sensitive to silicone contamination
• Meets UL94 V-0 flame resistance standard

Compatibility

Designed as an OEM-style push-to-connect replacement tee fitting for pneumatic and fluid systems using 8mm outside-diameter tubing and BSPT male branch connections.

Installation Notes

Installation should be performed by a licensed plumber, HVAC technician, or qualified pneumatic systems technician. De-pressurize and isolate the line before removing or inserting any push-to-connect fitting. Ensure tube ends are cut square, deburred, and clean before insertion to maintain a leak-free seal. Verify thread type compatibility — this fitting uses BSPT, which is not directly interchangeable with NPT threads.
