Parker W169PLP-8M-6R 90 Swivel Male Elbow Fitting 300 Psi

Product Description

The PARKER W169PLP-8M-6R is a push-to-connect 90-degree swivel male elbow fitting designed to connect 8mm outside diameter tubing to a male BSPT threaded port. Constructed from nickel-plated brass with a silicone-free grease lubrication, this fitting is rated for a maximum working pressure of 300 psi and a temperature range of 0 to 200 degrees F. The push-to-connect design allows fast, tool-free tube insertion, while the swivel body permits angular adjustment before final positioning. The silver body and yellow release button are consistent with standard push-connect fitting identification. Licensed HVAC technicians, plumbers, and fluid-system technicians working with metric tube runs and BSPT-ported equipment are the primary installers.

This fitting is suited for pneumatic and fluid control applications in both residential and light commercial systems where 8mm OD tubing must transition to a BSPT male threaded connection at a 90-degree angle. The swivel function accommodates routing constraints in tight panel or cabinet installations. It is a drop-in replacement or new-install fitting for systems requiring UL94 V-0 flame-resistance compliance and silicone-free media compatibility, making it appropriate for environments sensitive to silicone contamination such as certain painting or coating operations, as well as standard compressed-air and refrigerant-adjacent pneumatic circuits.

Key Features

• Push-to-connect design for fast, tool-free 8mm OD tube insertion and secure retention
• 90-degree swivel elbow body allows angular adjustment to suit routing before locking position
• Rated to 300 psi maximum working pressure
• Operating temperature range of 0 to 200 degrees F
• Nickel-plated brass construction with silicone-free grease for silicone-sensitive environments
• Meets UL94 V-0 flame resistance standard

Compatibility

Designed for use with 8mm outside diameter push-to-connect tubing systems terminating at a BSPT male threaded port in pneumatic or fluid control applications.

Installation Notes

Installation should be performed by a qualified technician familiar with push-to-connect pneumatic or fluid fittings. Always depressurize and de-energize the system fully before removing or installing any fitting. Confirm the mating port thread type is BSPT before installation, as BSPT and NPT threads are not interchangeable. To release the tube, depress the yellow release button fully while pulling the tube free.
