Parker W169PLP-8M-2R 90 Swivel Male Elbow Fitting 8mm

Product Description

The PARKER W169PLP-8M-2R is a push-to-connect 90-degree swivel male elbow fitting designed for tube-to-male connections in pneumatic and fluid systems. Constructed from nickel-plated brass with a silicone-free grease lubricant, it meets the UL94 V-0 flame resistance standard. The fitting accepts an 8mm outside-diameter tube on the push-to-connect end and terminates in a 1/8-inch BSPT male thread on the swivel end. Rated to 300 psi maximum working pressure with an operating range of 0 degrees F to 200 degrees F, this fitting is appropriate for compressed air, light hydraulic, and compatible fluid lines in commercial and industrial installations. HVAC technicians, plumbers, and industrial maintenance trades use this style of fitting where a quick, tool-free tube connection and directional routing flexibility are both required.

This fitting is suited for residential and light commercial applications where 8mm OD tubing meets a 1/8-inch BSPT male threaded port. The 90-degree swivel elbow configuration allows the installer to orient the tube run after the fitting is threaded into place, reducing stress on tubing and simplifying routing in tight spaces. Typical install scenarios include pneumatic control lines, instrument air connections, and fluid-handling assemblies found in HVAC controls, compressor plumbing, and process equipment panels.

Key Features

• Push-to-connect tube end accepts 8mm OD tubing for tool-free insertion and secure retention
• 90-degree swivel male elbow allows post-installation tube direction adjustment
• Nickel-plated brass construction provides corrosion resistance for air and compatible fluid service
• Rated to 300 psi maximum working pressure
• Operating temperature range of 0 degrees F to 200 degrees F
• UL94 V-0 flame resistance rating and silicone-free grease for broad system compatibility
• Yellow release button identifies the push-to-connect collet for quick tube removal

Compatibility

Designed as an OEM-style push-to-connect fitting for pneumatic and fluid systems using 8mm OD tubing with a 1/8-inch BSPT male threaded port.

Installation Notes

This fitting is installed by qualified HVAC technicians, plumbers, or industrial mechanics working on compressed-air or fluid-handling systems. Depressurize and isolate the system completely before removing or installing any fittings. Thread the BSPT male end into the receiving port using appropriate thread sealant compatible with the system fluid; do not overtighten, as brass fittings are susceptible to thread damage. Insert the tube fully into the push-to-connect end until it seats against the internal stop, then confirm retention with a gentle pull before returning the system to service.
