Parker W169PLP-6M-6R 90 Swivel Male Elbow Fitting 300 Psi

Product Description

The PARKER W169PLP-6M-6R is a push-to-connect 90-degree swivel male elbow fitting designed for tube-to-male tube connections in pneumatic and fluid-handling systems. Constructed from nickel-plated brass with a silicone-free grease lubricant and a UL94 V-0 flame-resistant release button, this fitting delivers a rated working pressure of 300 psi across a temperature range of 0 to 200 degrees F. The BSPT male thread and 6 mm outside-diameter tube connection make it a compact, reliable solution for routing lines in tight spaces. Licensed HVAC technicians, plumbers, and industrial service techs install this type of fitting where a right-angle tube-to-port connection is required without a separate elbow adapter.

This fitting is suited for residential and light commercial pneumatic control systems, compressed-air distribution, and fluid-handling installations that require a push-to-connect interface with a swiveling male end. The swivel design allows the body to rotate during installation so the tube exit angle can be oriented after the male thread is tightened, reducing stress on the connected tubing. It is appropriate for systems running within the rated pressure and temperature envelope where BSPT thread form is specified.

Key Features

• Push-to-connect tube entry accepts 6 mm outside-diameter tubing for tool-free tube insertion
• 90-degree swivel body rotates to allow tube-exit angle adjustment after thread engagement
• Nickel-plated brass construction resists corrosion in pneumatic and light fluid-handling service
• Rated to 300 psi maximum working pressure
• Operating temperature range of 0 to 200 degrees F
• UL94 V-0 flame-resistance rating on release button; silicone-free grease for compatibility with sensitive systems

Compatibility

Designed as an OEM-style push-to-connect fitting for pneumatic and fluid-handling systems specifying a 6 mm outside-diameter tube with a BSPT male thread connection at the port end.

Installation Notes

Installation is performed by a licensed plumber, HVAC technician, or qualified industrial mechanic. De-pressurize and lock out the system before removing any existing fittings or inserting new ones. Engage the BSPT male thread using an appropriate thread sealant compatible with the system fluid; do not use PTFE tape or sealants that contain silicone where silicone contamination is a concern. Insert tubing fully into the push-to-connect port until it seats, and verify retention by pulling back firmly on the tube before restoring system pressure.
