Parker W169PLP-4M-4R 90 Swivel Male Elbow 4mm 300 Psi

Product Description

The PARKER W169PLP-4M-4R is a push-to-connect 90-degree swivel male elbow fitting designed for tube-to-male tube connections in pneumatic and fluid control systems. Constructed from nickel-plated brass with a silicone-free grease finish, it accepts a 4mm outside diameter tube and terminates in a 1/4 inch BSPT male thread. The fitting is rated to 300 psi maximum working pressure and carries a UL94 V-0 flame resistance rating, making it appropriate for use in demanding control and instrumentation applications. The silver body with yellow release button provides a clear visual indicator for the push-to-connect release mechanism. HVAC technicians, pneumatic system installers, and fluid power mechanics are the typical trades handling this fitting.

This fitting is suited for use in pneumatic control lines, compressed air distribution, and light hydraulic circuits where a 90-degree directional change is needed at a threaded male port. The 4mm tube OD is common in European-standard and metric pneumatic tubing systems. Its temperature operating range of 0 degrees F to 200 degrees F supports installations in both refrigerated environments and heated mechanical rooms. The swivel elbow design allows the tube to be oriented after the fitting is threaded into the port, reducing installation stress on tubing runs.

Key Features

• Push-to-connect mechanism with yellow release button for quick, tool-free tube insertion and removal
• 90-degree swivel elbow allows post-installation tube orientation adjustment
• Nickel-plated brass construction for corrosion resistance in air and compatible fluid service
• 300 psi maximum working pressure rating
• UL94 V-0 flame resistance compliance and silicone-free grease for compatibility with sensitive systems
• BSPT thread type for use in metric and British-standard threaded ports

Compatibility

Designed for pneumatic and fluid control systems using 4mm outside diameter tubing and 1/4 inch BSPT male threaded ports. Consult system specifications to confirm thread standard and tube OD before installation.

Installation Notes

Installation should be performed by a qualified pneumatic or fluid power technician. Depressurize and isolate the system before removing or installing any fittings. Confirm that the port thread standard is BSPT before installation, as BSPT and NPT threads are not interchangeable. Insert tubing fully into the push-to-connect port until seated, and verify a secure connection by pulling back lightly on the tube before returning the system to pressure.
