Parker W169PLP-12M-6R 90 Swivel Male Elbow Fitting 300 Psi

Product Description

The PARKER W169PLP-12M-6R is a push-to-connect 90-degree swivel male elbow fitting designed for tube-to-male tube connections in pneumatic and fluid systems. Constructed from nickel-plated brass with a silicone-free grease lubricant, it accepts a 12mm outside diameter tube on the push-to-connect end and terminates in a BSPT male thread. The fitting is rated for a maximum working pressure of 300 psi and handles temperatures from 0 degrees F to 200 degrees F. The swivel design allows the male thread end to rotate during installation, reducing stress on connected lines. It meets the UL94 V-0 flame resistance standard and is identifiable by its silver body and yellow release button.

This fitting is suited for use in compressed air, pneumatic control, and compatible fluid-transfer applications in commercial and industrial environments. It is commonly installed in HVAC control systems, pneumatic actuator lines, and equipment manifolds where a 90-degree directional change is needed at a male-threaded port. The push-to-connect end allows fast, tool-free tube insertion, making it practical for service technicians working in tight equipment enclosures.

Key Features

• Push-to-connect end accepts 12mm OD tubing with no tools required for tube insertion
• 90-degree swivel male elbow allows thread-end rotation to ease alignment during installation
• Nickel-plated brass construction resists corrosion in typical pneumatic and fluid service environments
• Rated to 300 psi maximum working pressure
• Operates across a temperature range of 0 degrees F to 200 degrees F
• UL94 V-0 rated for flame resistance; silicone-free grease for compatibility with sensitive systems

Compatibility

Designed as an OEM-style push-to-connect fitting for systems using 12mm OD tubing with BSPT male threaded ports requiring a 90-degree swivel elbow connection.

Installation Notes

Installation and service should be performed by qualified technicians familiar with pneumatic or fluid-line systems. Depressurize and isolate the line completely before removing or installing fittings. Verify that the mating port thread type is BSPT before installation, as BSPT and NPT threads are not interchangeable. Insert tubing fully into the push-to-connect end until it seats, and confirm retention before returning the system to pressure.
