Parker W169PLP-10M-8R 90 Swivel Male Elbow 10mm 300 Psi

Product Description

The PARKER W169PLP-10M-8R is a push-to-connect 90-degree swivel male elbow fitting designed for tube-to-male connections in pneumatic and fluid-handling systems. Constructed from nickel-plated brass, this fitting accepts a 10mm outside diameter tube on the push-in end and terminates in a BSPT male thread on the other. It carries a maximum working pressure rating of 300 psi and is rated for temperatures from 0 degrees F to 200 degrees F. The yellow release button provides controlled tube disengagement. This fitting is typically installed by HVAC technicians, plumbers, and industrial maintenance professionals working with push-to-connect pneumatic or fluid lines.

This fitting is suited for residential and light commercial pneumatic plumbing and fluid-conveyance applications where a 90-degree directional change is needed between a tube run and a male-threaded port. The swivel feature allows rotational adjustment after assembly, simplifying alignment in tight or congested panel environments. The UL94 V-0 flame resistance standard and silicone-free grease make it appropriate for use in environments where silicone contamination must be avoided, such as paint-booth or sensor-sensitive systems.

Key Features

• Push-to-connect design accepts 10mm OD tube without tools for fast, repeatable connections
• 90-degree swivel elbow allows post-installation rotational adjustment for precise alignment
• Nickel-plated brass construction for corrosion resistance and durability
• Rated to 300 psi maximum working pressure
• Operating temperature range: 0 degrees F to 200 degrees F
• Silicone-free grease — safe for silicone-sensitive applications
• Meets UL94 V-0 flame resistance standard

Compatibility

Designed for use with 10mm outside diameter push-to-connect tubing and BSPT male-threaded ports. Intended for pneumatic and compatible fluid-handling systems requiring a 90-degree tube-to-male swivel connection.

Installation Notes

Installation is typically performed by licensed plumbers, HVAC technicians, or industrial maintenance technicians. Before installing or removing this fitting, depressurize and isolate the line completely. To release the tube, depress the yellow release button evenly while pulling the tube straight out. Ensure the BSPT male thread is sealed with an appropriate thread sealant or tape compatible with the system media and pressure rating before making up the threaded joint.
