Parker W169PLP-10M-4R 90 Swivel Male Elbow 10mm 300 Psi

Product Description

The PARKER W169PLP-10M-4R is a push-to-connect 90-degree swivel male elbow fitting designed for tube-to-male tube connections in pneumatic and fluid systems. Constructed from nickel-plated brass, it accepts a 10mm outside diameter tube on the push-to-connect end and terminates in a 1/4 inch BSPT male thread. The fitting is rated to 300 psi maximum working pressure and handles temperatures from 0 degrees F to 200 degrees F. The swivel design allows the male thread end to rotate independently, simplifying alignment during installation. It is silicone-free and meets the UL94 V-0 flame resistance standard, making it suitable for use in sensitive instrumentation and automation environments.

This fitting is used in compressed air, pneumatic control, and general fluid transfer lines where a 90-degree direction change is required between a tube run and a male-threaded port. Typical applications include HVAC pneumatic controls, industrial automation panels, and light fluid handling systems. The push-to-connect mechanism allows fast, tool-free tube insertion, which speeds up assembly and field service work. The yellow release button enables tube removal without cutting or damaging the tube. It is installed by HVAC technicians, pneumatic system assemblers, and mechanical contractors working on equipment with BSPT-ported components.

Key Features

• Push-to-connect design allows tool-free tube insertion and removal via yellow release button
• 90-degree swivel male elbow configuration simplifies port alignment in tight spaces
• Nickel-plated brass construction provides corrosion resistance in pneumatic and fluid service
• Rated to 300 psi maximum working pressure
• Operating temperature range from 0 degrees F to 200 degrees F
• Silicone-free grease and UL94 V-0 flame resistance compliance for use in sensitive instrumentation environments

Compatibility

Designed as an OEM-style push-to-connect replacement fitting for pneumatic and fluid systems using 10mm OD tubing and 1/4 inch BSPT male-threaded ports.

Installation Notes

Installation is performed by licensed HVAC technicians or qualified mechanical contractors. Before servicing any pneumatic or pressurized fluid line, depressurize the system completely and confirm pressure has been relieved at the work point. Ensure the tube end is cut cleanly and squarely with no burrs before inserting into the push-to-connect port. Verify the receiving port is BSPT-threaded, as BSPT is not interchangeable with NPT; use appropriate thread sealant per the system manufacturer and applicable plumbing codes.
