PARKER U341N05NH1B NAMUR Solenoid Valve

Product Description

The Parker U341N05NH1B is a NAMUR solenoid valve designed for use in process and industrial settings. This valve operates as either a three-way or five-way valve and can handle both dry and lubricated air. It has a high flow direct mount design and is built to be explosion-proof, making it suitable for hazardous locations and outdoor applications.

• Compact design accommodating high flow rates up to one point two Cv.
• Fail-safe operational design.
• Meets CSA and FM standards for hazardous environments.

Product Highlights

The Parker U341N05NH1B offers reliable performance in demanding conditions.

Product Information

Standard Information

• Item Name: NAMUR Solenoid Valve
• Type: 2-Position, High Flow Direct Mount, Explosion Proof

Technical Specifications

• Nominal Size: 1/4 IN
• Connection Type: NPT
• Number Of Ports/Ways: 3 Or 5-Way
• Media: Dry Or Lubricated Air
• Pressure Rating: 37 - 150 PSI
• Temperature Rating: 37 - 122 DEG F
• Orifice: 0.27 IN
• Body Material: Aluminum
• Seal Material: FKM
• Coil Insulation Class: Class H
• Power Rating: 5 W
• Voltage Rating: 24 VDC
• Enclosure: NEMA 7, 9
• Electrical Connection: Hazardous Location Conduit
• Industry Standards: CSA And FM Approval For Class 1, Group A,B,C,D And Class II, Groups E,F,G. Meets Ex m T4 Zone 1
• Flow Co-Efficient (Cv): 1.2
• Brand: Parker
• Anti-Water Hammer: No
