Parker SVHN8-8M Hydraulic Hose Mpt Fitting 3750 Psi

Product Description

The PARKER SVHN8-8M is a straight male pipe thread (MPT) hydraulic hose fitting designed for high-pressure fluid connections in industrial and mobile equipment applications. Built from stainless steel with a 1/2-inch NPT thread and a 1/2-inch hose size, this Series H fitting handles working pressures up to 3,750 psi. At 2.46 inches in overall length and 0.32 pounds, it is a compact, durable component suited for licensed hydraulic technicians and equipment mechanics working on demanding fluid power systems. The threaded connection type provides a secure, leak-resistant seal when properly torqued to applicable standards.

This fitting is rated for use on industrial hydraulic lines, mobile equipment hydraulic circuits, and water and coolant lines. The stainless steel construction offers resistance to corrosion, making it appropriate for environments where moisture, coolant fluids, or aggressive media are present. The straight body geometry suits direct inline connections where angular fittings are not required. Technicians working on agricultural machinery, construction equipment, or industrial fluid systems will find this fitting compatible with standard 1/2-inch hydraulic hose assemblies using NPT thread interfaces.

Key Features

• 3,750 psi maximum working pressure for high-pressure hydraulic service
• Stainless steel construction for corrosion resistance in harsh environments
• 1/2-inch NPT threaded connection for compatibility with standard pipe thread fittings
• Straight body shape for direct inline hose-to-port connections
• Compact at 2.46 inches overall length and 0.32 pounds
• Series H design suitable for industrial hydraulic and coolant line applications

Compatibility

Designed for use with industrial hydraulic lines, mobile equipment hydraulic circuits, and water and coolant lines requiring a 1/2-inch NPT male pipe thread fitting at 3,750 psi working pressure.

Installation Notes

Installation should be performed by a qualified hydraulic technician or equipment mechanic familiar with fluid power systems. Depressurize and bleed the hydraulic circuit completely before removing or installing any fitting. Apply appropriate thread sealant compatible with the system fluid and verify thread engagement meets the fitting manufacturer and system design requirements. Inspect the mating port threads for damage before assembly to ensure a leak-free connection.
