Sporlan 904927 ADRI 3/8 Inch ODF Discharge Bypass Valve Internally Equalized 0-55 PSIG

Product Description

The Sporlan ADRI 3/8 inch ODF Discharge Bypass Valve, model number 904927, is designed for precise control over HVAC and refrigeration systems. This internally equalized valve is engineered to maintain efficiency and performance.

• Adjustable pressure settings from 0 to 55 PSIG for versatile application
• Constructed with durable brass body and copper connections
• Externally equalized to enhance control stability

Product Highlights

This valve features an optional inlet strainer and offers a range of adjustable settings. It is particularly effective in preventing coil icing and maintaining compressor suction pressure during low load conditions.

Product Information

Standard Information

• Brand: Sporlan
• MPN: 904927
• Category: HVAC Supplies, HVAC and Refrigeration Valves, Discharge By-Pass Valves

Technical Specifications

• Body Material: Brass
• Connection Type: Solder
• Connection Size: 3/8 inch ODF
• Port Size: 5/32 inch
• Max Pressure: 55 PSIG
• Dimensions: Weight: 5.5 pounds, Depth: 11 inches, Width: 5 inches, Height: 5 inches
