Sporlan 401610 Catch-All Filter-Drier 5/8ODF Liquid Line C-415-S

Product Description

The Sporlan 401610 Catch-All Filter-Drier is designed for effective contaminant removal in refrigeration systems. This liquid line filter-drier features a 5/8 inch ODF connection, making it suitable for various applications in HVAC and refrigeration units.

• Leak-proof shell
• Solid copper sweat fittings
• Outlet safety filter

Product Highlights

Sporlan 401610 is a reliable filter-drier that ensures efficient moisture and acid removal from refrigerants. It is UL listed and compatible with all commercially available HCFC and HFC refrigerant/lubricant combinations. The maximum working pressure is 650 psi.

Product Information

Standard Information

• Brand: Sporlan Valves
• MPN: 401610

Technical Specifications

• Capacity: 41 cu in
• Connection Ends: ODF
• Size: 5/8 inch
• Length: 11.5 inches
• Width: 4.0 inches
• Height: 4.0 inches
• Diameter: 3.50 inches
• Master Product Group: Contaminant Control Products
• Product Group: Sealed Filter-Driers
• Item Class: C-410'S
• Price Group: CA
• Harmonized Code: 8421.29.0065
• Pieces Per Case: 10
• Case Weight: 46.60 lbs
• Case Length: 20.00 inches
• Case Width: 12.00 inches
• Case Height: 8.50 inches
• Cases Per Layer: 8
• Cases Per Pallet: 40
• Pallet Weight: 1,966.00 lbs
• Pallet Length: 48 inches
• Pallet Width: 40 inches
• Pallet Height: 50 inches
• Series-Brand: Catch-All
