SPORLAN 401432 Catch-All Filter-Drier 5/8 inch SAE Liquid Line C-305-HH

Product Description

The Sporlan 401432 Catch-All Filter-Drier is designed for efficiency in refrigerant handling. This advanced filter-drier unit features solid copper sweat fittings and a molded porous core made from blended desiccants, ideal for HVAC specialists and refrigeration engineers. It effectively removes contaminants such as moisture, acid, dirt, and sludge from the refrigerant system, ensuring optimal performance and longevity of HVAC systems.

• Leak-proof shell enhances system reliability.
• Integrated safety outlet filter for enhanced protection.
• Compatible with all HCFC and HFC refrigerant/lubricant combinations.

Product Highlights

This sealed type filter-drier has a capacity of 30 cubic inches and is designed with a Schrader type pressure tap on the inlet. Its robust construction allows a maximum working pressure of 650 psi, making it suitable for diverse environmental conditions.

Product Information

Technical Specifications

• Capacity: 30 cu in
• Connection Ends: SAE
• Size: 5/8 inch
• Length: 11.5 inches
• Width: 3.5 inches
• Height: 3.5 inches
• Diameter: 3.00 inches
