SPORLAN 401310 Catch-All Filter-Drier Liquid Line 5/8 inch C-305-S-HH

Product Description

The Sporlan 401310 Catch-All Filter-Drier is designed to provide superior filtration and moisture removal in refrigeration and air conditioning systems. It features a robust, leak-proof shell with solid copper sweat fittings.

• Efficient performance with a maximum working pressure of 650 psi.
• Equipped with a dual desiccant core, ensuring thorough contaminant removal.
• Molded porous core to trap acids, moisture, and other particles effectively.

Product Highlights

This filter-drier is particularly adept at filtering out scale, solder particles, carbon, sludge, dirt, and foreign matter with minimal pressure drop. Its unique blended desiccant core also removes moisture and acid, safeguarding your refrigeration system components.

Technical Specifications

• Capacity: 30 cubic inches
• Connection Type: 5/8 inch ODF
• Dimensions: 11.5 x 3.5 x 3.5 inches
• Diameter: 3.00 inches
• Available for: All HCFC and HFC refrigerant/lubricant combinations
• UL Listed: Yes
