Sporlan 400288 C-053 3/8 Inch SAE Filter-Drier

Product Description

The Sporlan 400288 C-053 SAE Filter-Drier is a critical component for any refrigeration or air-conditioning system, ensuring cleanliness and moisture control within refrigerants. It features a robust design capable of handling pressures up to 650 psi, suitable for all HCFC and HFC refrigerant/lubricant combinations.

• Leak-proof shell design with solid copper sweat fittings ensures a secure, durable connection.
• Effectively filters out scale, solder particles, carbon, and other contaminants with minimal pressure drop.
• Integrated safety outlet filter and a molded porous core for optimal moisture and acid removal.

Product Highlights

The Sporlan C-053 Filter-Drier's unique design includes a UL Listed mold that absorbs and retains moisture and acid within the desiccant granules, ensuring the purity of the circulating refrigerant. It also features specialized configurations such as the CAP for capillary tube systems and the type T Schrader® pressure tap.

Product Information

Technical Specifications

• Connection Type: 3/8 Inch SAE
• Capacity: 5 cubic inches
• Size: 3/8 inch
• Length: 5.8 inches
• Width: 2.5 inches
• Height: 2.5 inches
• Diameter: 2.44 inches
• Weight: 0.82 lbs
