Parker PX-00030 Female Jic 37 Swivel Fitting 1/2 in Brass

Product Description

The PARKER PX-00030 is a straight female JIC 37-degree swivel fitting designed for use in hydraulic hose assemblies. Built from brass, this fitting connects a 1/2-inch inside diameter hose to a 7/8-14 UNF threaded port using a standard JIC 37-degree flare seat. The swivel design allows the hose end to rotate during installation, reducing torque transfer to the hose and making routing easier in tight spaces. At 2.03 inches in overall length, it is a compact, direct-fit component for medium-duty hydraulic lines. Licensed technicians and fluid-power mechanics working on mobile equipment, industrial machinery, or hydraulic tool circuits will recognize this as a common hose-end termination fitting.

This fitting is suited for hydraulic fluid-power systems where a straight, female JIC hose-end connection is required at a 7/8-14 threaded port. It is compatible with 1/2-inch ID hydraulic hose and belongs to Parker series 91N. Typical applications include equipment hydraulics, agricultural machinery, construction equipment, and industrial hydraulic circuits where JIC 37-degree flare connections are specified. It is sold in packages of five.

Key Features

• Straight swivel design reduces hose twist during installation and routing
• Brass construction provides corrosion resistance in hydraulic fluid environments
• JIC 37-degree flare seat ensures a reliable, leak-resistant metal-to-metal connection
• 7/8-14 UNF thread size is a widely used standard in hydraulic plumbing
• Compact 2.03-inch overall length fits confined hose-end assemblies
• Parker series 91N fitting for consistent OEM and aftermarket fitment

Compatibility

Designed for use with 1/2-inch inside diameter hydraulic hose assemblies requiring a straight female JIC 37-degree swivel hose-end fitting with a 7/8-14 UNF thread. Compatible within the Parker series 91N fitting line.

Installation Notes

Installation should be performed by a qualified fluid-power technician or hydraulic specialist. Depressurize and isolate the hydraulic circuit completely before disconnecting or assembling any fittings. Inspect the JIC flare seat and mating port for damage or contamination before assembly. Do not overtighten brass fittings; follow the fitting manufacturer's recommended finger-tight-plus-turns procedure for JIC connections rather than relying on a torque value not specified for this part.
