Parker PT-00392 Steel Flared Tube Nut 3/8 in 37 Degree

Product Description

The PARKER PT-00392 is a steel flared tube nut designed for use with 3/8 inch outside diameter tubing at a 37-degree flare angle. It provides a secure, leak-resistant mechanical connection at the flare end of hydraulic, pneumatic, or fluid transfer lines. Rated to 7500 psi maximum working pressure and 500 degrees F maximum working temperature, this nut suits demanding industrial and fluid power applications. Licensed plumbers, hydraulic technicians, and HVAC-R service pros install this type of fitting when assembling or servicing flared tube connections. Sold in packages of 5.

This fitting is suited for high-pressure fluid lines requiring reliable flare-end connections. Typical install scenarios include hydraulic circuits, refrigeration line sets, fuel lines, and compressed air systems where 37-degree JIC or SAE-style flare fittings are specified. The 37-degree flare angle conforms to ISO 8434-2, SAE J514, SAE 070118, and SAE 080118 standards, making it compatible with tubing assemblies built to those specifications. It is appropriate for both industrial and mobile equipment applications.

Key Features

• 37-degree flare angle per ISO 8434-2 and SAE J514 standards
• Rated to 7500 psi maximum working pressure
• Rated to 500 degrees F maximum working temperature
• 3/8 inch tube OD flare end connection
• Steel construction for strength and durability in fluid power service
• Sold in a package of 5 units

Compatibility

Designed for use with 3/8 inch OD tubing in 37-degree flare end assemblies meeting ISO 8434-2, SAE J514, SAE 070118, and SAE 080118 standards.

Installation Notes

Installation is typically performed by licensed plumbers, hydraulic technicians, or HVAC-R technicians working on flared tube assemblies. De-pressurize and isolate the line before disassembly or connection. Use a calibrated flaring tool to ensure the tube end meets the 37-degree flare angle specification before threading the nut. Do not overtighten; follow applicable SAE or system manufacturer torque guidelines for the line size in use.
