Parker PPB4ME2-MG Male Elbow Tube Fitting 1/4 X 1/8 in

Product Description

The PARKER PPB4ME2-MG is a push-to-connect male elbow tube fitting designed for quick, tool-free connections in pneumatic and fluid-handling systems. Molded from polypropylene, this fitting handles working pressures up to 230 psi and transitions a 1/4-inch OD tube to a 1/8-inch male port. The elbow configuration routes tubing at a 90-degree angle, which is useful in tight installations where a straight fitting would not clear adjacent components. HVAC technicians, plumbers, and industrial maintenance techs install this type of fitting in low-pressure air, water, and chemical lines where corrosion resistance and fast assembly are priorities.

This fitting is suited for residential and light commercial applications involving pneumatic control tubing, water treatment lines, and general fluid distribution. Its polypropylene construction resists many common chemicals and moisture, making it a practical choice for condensate management, reverse osmosis systems, refrigeration drain lines, and similar service environments. The compact body measures 0.94 inches in height, 0.94 inches in length, and 0.66 inches in width, so it fits into space-constrained enclosures and panel cutouts without modification.

Key Features

• Push-to-connect design allows tool-free tube insertion and secure retention
• 90-degree male elbow routes 1/4-inch OD tubing to a 1/8-inch male port
• Polypropylene construction provides corrosion and chemical resistance
• Rated to 230 psi working pressure
• Compact profile: 0.94 x 0.94 x 0.66 inches overall

Compatibility

Designed as an OEM-style push-to-connect replacement fitting for pneumatic control, fluid handling, and low-pressure plumbing systems using 1/4-inch OD tubing with a 1/8-inch male port connection.

Installation Notes

Installation does not require tools — cut tubing square, deburr the end, and push it fully into the fitting until it seats against the internal stop. To release tubing, depress the collet ring while pulling the tube out. Shut off system pressure and depressurize the line completely before servicing any fitting. Verify that the tubing material and fluid compatibility are appropriate for the application before installation.
