Parker PC514 90 Degree Hose Barb Coupler 0.5 in Brass

Product Description

The PARKER PC514 is a 90-degree hose barb coupler designed for industrial fluid handling applications where reliable, leak-resistant connections are required. Built from brass, this non-valved fitting accepts a 0.5-inch inside diameter hose and handles a maximum working pressure of 200 psi. It operates across a wide temperature range, from -20 degrees F to 400 degrees F, making it suitable for demanding thermal environments. The PC514 belongs to Parker's Moldmate series and is intended for installation by maintenance technicians and fluid system specialists working with pressurized coolant or process fluid lines.

This coupler is rated for use with die casting equipment and mold coolant lines, where consistent flow and secure barb retention are critical. The 90-degree angle allows routing in tight spaces or along panel edges without sharp hose bends. The threaded connection type provides a secure, positional fit at the port end, while the non-valved design allows full, unrestricted flow when connected. It is well suited for shop floor and production environments running high-temperature mold cooling circuits.

Key Features

• 90-degree hose barb geometry for space-efficient routing in confined installations
• Brass construction provides corrosion resistance in coolant and water-based fluid service
• 200 psi maximum working pressure rating for pressurized coolant circuits
• Wide service temperature range: -20 degrees F to 400 degrees F
• Non-valved design allows unrestricted flow with no internal restriction
• Part of the Parker Moldmate series, engineered for die casting and mold cooling applications

Compatibility

Designed for use with die casting equipment and mold coolant lines as part of the Parker Moldmate series. Accepts 0.5-inch inside diameter hose with a threaded port connection.

Installation Notes

Installation should be performed by a qualified technician familiar with pressurized fluid systems. Depressurize and drain the coolant circuit fully before removing or installing any fittings. Ensure hose is fully seated over the barb and secured with an appropriate clamp rated for the system pressure. Follow applicable facility safety procedures and equipment manufacturer guidelines when working on mold cooling circuits.
