Parker PA20SAN5S050A 2-Way Angle Body Solenoid Valve

Product Description

The Parker PA20SAN5S050A is a 2-way angle body solenoid valve ideal for pneumatic operations. This valve operates in a normally closed mode and is made from durable 304 stainless steel. It is designed specifically for liquid applications, effectively managing flow under the seat.

• 2-Way normally closed functionality
• 3/4 inch NPT port size
• Maximum operating pressure of 145 PSI

Product Highlights

This valve is perfect for applications that require precise flow control of liquids. It can accommodate maximum operating pressures up to 145 PSI while utilizing PTFE seals for durability.

Product Information

Standard Information

• Valve Type: 2-Way
• Function: Normally Closed

Technical Specifications

• Port Size: 3/4 inch
• Media: Liquids (Anti-water Hammer) - Flow under seat
• Body Material: 304 Stainless Steel
• Maximum Operating Pressure: 145 PSI
• Minimum Pilot Air Pressure: 65.3 PSI
• Orifice 1 Size: 0.71 inch
• Flow Factor 1: 10.5021
• Seal Material: PTFE
• Number of Ports: 2
• Actuation: Pneumatic Operated
• Actuator Size: 50 mm
• Actuator Housing Material: Aluminum
• Mounting: Pipe Mounting
• Port Type: NPT
• Weight: 1.98 lbs
• Maximum Pilot Air Pressure: 145 PSI
• Minimum Fluid Temperature: 14 F
• Maximum Fluid Temperature: 356 F
