Parker P3YRA96BNFN Air Regulator 3/4 Npt 254 Psi 380 Cfm

Product Description

The PARKER P3YRA96BNFN is a hi-flow compressed air regulator designed to maintain consistent downstream pressure in industrial and commercial compressed air systems. Built from aluminum and rated for a maximum supply pressure of 254 psi, it handles airflow up to 380 CFM, making it well suited for high-demand pneumatic circuits. The 3/4 inch NPT end connections fit directly into standard compressed air distribution lines. A built-in pressure gauge and a 1/4 inch gauge port thread are included, and the unit supports modular connections for integration into filter-regulator-lubricator assemblies. A relief function vents excess pressure when downstream demand drops.

The P3YRA96BNFN belongs to the Parker P3Y Series and is intended for compressed air service in manufacturing, industrial maintenance, and process pneumatic applications. It performs in environments where high flow capacity and precise pressure control are both required. The regulator operates across a working pressure range of 0 to 174 psi output and tolerates temperatures down to 14 degrees F, allowing use in cold-storage or outdoor-adjacent installations where ambient temperatures can drop below freezing.

Key Features

• Hi-flow design rated at 380 CFM for high-demand pneumatic circuits
• Maximum supply pressure of 254 psi with an output range of 0 to 174 psi
• 3/4 inch NPT end connections for standard compressed air line integration
• Built-in pressure gauge with 1/4 inch gauge port thread
• Modular connection support for FRL assembly configurations
• Integrated relief function for downstream pressure protection
• Aluminum body construction for lightweight, corrosion-resistant service

Compatibility

Designed for compressed air service and compatible with Parker P3Y Series modular FRL systems. Suitable as an OEM-style or replacement hi-flow regulator for industrial pneumatic lines using 3/4 inch NPT connections.

Installation Notes

Installation should be performed by a qualified pneumatic systems technician or industrial maintenance professional. Depressurize and lock out the compressed air supply completely before removing any existing regulator or fittings. Apply thread sealant appropriate for compressed air service to all NPT connections and verify there are no leaks before returning the system to full operating pressure. Follow applicable facility safety procedures and local compressed air system codes during installation and commissioning.
