Parker P3YLA98LSNN Air Lubricator 390 Cfm 1 Inch Npt

Product Description

The PARKER P3YLA98LSNN is a high-flow compressed air lubricator designed to introduce controlled amounts of oil mist into a pneumatic system downstream of a filter and regulator. Rated at 390 CFM, it handles high-demand air circuits without creating excessive pressure drop. The body is machined aluminum for durability in industrial environments, and the bowl is polypropylene with a built-in bowl guard for added protection. A 1 inch NPT port size suits mainline or branch-line installations where flow capacity is a priority. Licensed HVAC techs, maintenance mechanics, and industrial pneumatic technicians install this unit as part of a filter-regulator-lubricator (FRL) assembly.

This lubricator fits industrial compressed air systems requiring sustained high flow rates, such as production lines, large pneumatic actuator circuits, or multi-tool air distribution manifolds. It is part of the Parker P3Y series, which supports modular connections for inline assembly with compatible P3Y series filters and regulators. The sight glass allows visual confirmation that oil is feeding correctly without shutting down the line. At 9.7 inches tall and 3.5 inches wide, it is sized for panel or inline mounting where space allows.

Key Features

• 390 CFM high-flow rating supports demanding industrial pneumatic circuits
• 1 inch NPT port for mainline compressed air integration
• Aluminum body construction for durability in industrial service
• Polypropylene bowl with bowl guard for operator protection
• Includes sight glass for visual oil-feed verification without line shutdown
• Modular connection supports inline assembly with P3Y series FRL components
• 16.9 oz bowl capacity reduces refill frequency on high-consumption systems

Compatibility

Designed for use within the Parker P3Y series modular FRL system. Modular connection support allows direct inline assembly with compatible P3Y series filter and regulator units.

Installation Notes

Installation should be performed by a qualified pneumatic or industrial maintenance technician. Depressurize and lock out the air supply before installing or servicing the lubricator. Install downstream of the filter and regulator in the FRL assembly, with airflow direction matching the arrow marked on the body. Use appropriate thread sealant on NPT connections and verify all joints are leak-free before returning the system to service.
