Parker P2FCH453 Solenoid Valve 120V Ac 232 Psi Normally Closed

Product Description

The PARKER P2FCH453 is a normally closed solenoid valve designed for precise fluid control in industrial and commercial systems. Built with a thermoplastic body and an FKM fluorocarbon seal, this valve delivers chemical resistance suited to demanding process environments. It operates on 120 volts AC and handles working pressures from 22 psi up to 232 psi. The Class F coil rating indicates suitability for elevated-temperature service, with a maximum temperature rating of 158 degrees F. A licensed technician or pipefitter typically specifies and installs this valve in fluid control assemblies where fail-safe normally closed operation is required.

The P2FCH453 is engineered for use with the Parker Viking Xtreme Valve system. Its 1/2 NPT conduit connection with 18-inch leads simplifies integration into electrical enclosures and control panels. The IP 65 enclosure rating means the coil assembly resists dust ingress and low-pressure water jets, making it appropriate for wet or wash-down service areas. This valve suits applications in chemical processing, irrigation control, water treatment, and similar fluid-handling systems where a compact, normally closed solenoid is specified.

Key Features

• Normally closed fail-safe operation — valve closes when power is removed
• Thermoplastic body with FKM fluorocarbon seal for chemical compatibility
• 120V AC coil with Class F insulation rating
• Operating pressure range: 22 psi to 232 psi
• IP 65 rated coil enclosure for dust and water resistance
• 1/2 NPT conduit connection with 18-inch leads for straightforward electrical hookup

Compatibility

Designed for use with the Parker Viking Xtreme Valve system. Verify port size, pressure range, and media compatibility against system specifications before installation.

Installation Notes

Installation should be performed by a licensed pipefitter or qualified technician in accordance with applicable local plumbing and electrical codes. De-energize the circuit and isolate the line pressure before removing or installing the valve. The 1/2 NPT conduit connection should be sealed with listed conduit fittings to maintain the IP 65 rating. Confirm that the media temperature and chemical composition are within the rated limits of the FKM seal and thermoplastic body before commissioning.
