Parker P2FCH447 Solenoid Valve 12V Normally Closed

Product Description

The PARKER P2FCH447 is a direct-acting, normally closed solenoid valve designed for precise fluid control in demanding industrial and commercial applications. The valve body is constructed from thermoplastic with an FKM fluorocarbon seal, making it well suited for use with a range of aggressive media. It operates on 12 volts DC and carries a Class F coil rating, indicating a high-temperature coil insulation class. With a Cv factor of 0.0350 and a minimum working pressure of 22 psi, this valve is built for low-flow, controlled-pressure circuits. Licensed technicians and instrumentation professionals are the primary installers.

The P2FCH447 is specified for use with the Parker Viking Xtreme Valve system. It fits applications where a normally closed, de-energized-safe state is required, meaning the valve remains closed unless the coil is energized. The coil lead connection is a 1/2 NPT conduit fitting with 18-inch leads, supporting straightforward integration into enclosures and control panels. The IP 65 rating makes it appropriate for outdoor or wash-down environments where moisture and dust ingress must be controlled. This valve is a fit for both OEM equipment builds and field service replacements within compatible Parker valve assemblies.

Key Features

• Direct-acting, normally closed operation for fail-safe de-energized state
• Thermoplastic body with FKM fluorocarbon seal for chemical compatibility
• 12-volt DC operation with Class F coil insulation rating
• IP 65 ingress protection rating for outdoor and wash-down environments
• 1/2 NPT conduit connection with 18-inch leads for control panel integration
• Cv factor of 0.0350 and 22 psi minimum working pressure for low-flow circuits

Compatibility

Specified for use with the Parker Viking Xtreme Valve system. Confirm system voltage, pressure range, and media compatibility before installation.

Installation Notes

Installation should be performed by a licensed technician or qualified instrumentation professional. De-energize and depressurize the system fully before removing or installing the valve. Verify that supply voltage matches the 12-volt DC coil rating and that the conduit connection is properly sealed to maintain the IP 65 rating. Consult applicable electrical codes and the Parker Viking Xtreme Valve documentation before commissioning.
