Parker KP46899 Code 61 Flange Elbow 1 Inch Steel

Product Description

The PARKER KP46899 is a Code 61 flange elbow fitting designed for hydraulic hose assemblies requiring a secure, leak-resistant connection at a 90-degree angle. Built from steel, this fitting meets the SAE J518 Code 61 flange standard and is sized for 1-inch hose diameter (16 mm). It is used in medium- to high-pressure hydraulic circuits found in industrial machinery, mobile equipment, and agricultural systems. Licensed hydraulic technicians and fluid power specialists are the primary installers of this component.

This fitting is suited for hydraulic systems where a straight hose run is not practical and a right-angle connection is needed at a pump, valve, or actuator port. The Code 61 flange pattern is a common interface on hydraulic pumps, motors, and manifolds operating in demanding industrial and mobile applications. The 1-inch hose size makes it appropriate for moderate-flow hydraulic lines in both stationary and mobile equipment configurations.

Key Features

• Code 61 flange pattern per SAE J518 for medium- to high-pressure hydraulic service
• Elbow configuration allows routing around obstructions without bending hose
• Steel construction provides durability in high-pressure hydraulic environments
• 1-inch hose diameter (16 mm) compatibility for common hydraulic line sizes
• Single-piece package quantity suitable for individual repair or assembly use

Compatibility

Designed as an OEM-style replacement or new-assembly fitting for hydraulic hose systems requiring a 1-inch Code 61 flange elbow connection.

Installation Notes

Installation should be performed by a qualified hydraulic technician or fluid power specialist. Depressurize and lock out the hydraulic system completely before disassembling any fittings or hose ends. Inspect mating flange faces and O-ring grooves for contamination or damage prior to assembly. Follow the equipment manufacturer's torque specifications for flange bolts to ensure a leak-free joint.
