Parker KP46882 Hydraulic Hose Swivel Fitting 0.375 in Female Jic

Product Description

The PARKER KP46882 is a steel hydraulic hose swivel fitting designed for use in high-pressure hydraulic systems. It features a 90-degree elbow configuration with a female JIC shaft type and a 3/4-16 threaded connection. The fitting accepts hoses with a 0.375 inch (3/8 inch) inside diameter, corresponding to hose size 6. The swivel design allows rotational adjustment during installation, reducing stress on the hose assembly and simplifying routing in tight spaces. Licensed hydraulic technicians, fluid power mechanics, and industrial maintenance professionals typically install this fitting on mobile and stationary hydraulic equipment.

This fitting is suited for hydraulic plumbing applications in both mobile equipment and stationary industrial systems where a 90-degree elbow transition is required. The threaded female JIC interface is common in medium- and high-pressure hydraulic circuits. It is rated for use with a broad range of Parker hose series, making it a versatile replacement or service fitting for field and shop repairs.

Key Features

• 90-degree elbow swivel configuration for flexible hose routing
• Female JIC thread interface for secure, leak-resistant connections
• 3/4-16 thread size for compatibility with standard hydraulic fittings
• Steel construction for durability in high-pressure hydraulic environments
• 0.375 inch (3/8 inch) hose inside diameter, hose size 6
• Meets ISO 12151-5 standards; California Proposition 65 listed

Compatibility

Designed for use with Parker 187 (TC, ST), 302, 304, 387 (TC, ST), 422, 424, 426, 436, 471TC, 471ST, 472TC, 482TC, 482ST, 487 (TC, ST), 722 (TC, ST), 787 (TC, ST), 797 (TC, ST), and 881 hose series.

Installation Notes

Installation should be performed by a qualified fluid power technician or hydraulic mechanic. Depressurize and isolate the hydraulic circuit completely before removing or installing any fittings. Inspect mating threads and sealing surfaces for damage before assembly. Torque to the fitting manufacturer specifications for JIC connections; do not over-tighten swivel nuts, as this can damage the sealing surface.
