Parker KP46881 Hydraulic Hose Fitting 90 Degree Elbow

Product Description

The PARKER KP46881 is a 90-degree elbow hydraulic hose fitting designed for use in high-pressure hydraulic systems across industrial and mobile equipment applications. Machined from steel with a female JIC threaded connection, this fitting accepts a 9/16-18 thread and is sized for hoses with a 0.375 inch (3/8 inch) inside diameter, corresponding to a size 6 hose designation. The fitting allows a clean 90-degree transition in tight routing situations where a straight fitting cannot clear frame rails, bulkheads, or other obstructions. Installation is performed by hydraulic technicians and mechanical service professionals working on fluid power systems.

This elbow fitting is suited for both stationary and mobile hydraulic circuit assemblies where a perpendicular hose-to-port connection is required. It is appropriate for medium- and high-pressure hydraulic lines running fluid power to actuators, valves, cylinders, and motors. The female JIC interface is widely used in industrial hydraulic systems and pairs directly with standard JIC male flare fittings. Each package contains 2 pieces, making it practical for jobs requiring matched pairs at both ends of a hose run.

Key Features

• 90-degree elbow geometry for tight routing and bend-radius clearance
• Steel construction for durability in hydraulic pressure service
• Female JIC threaded connection, 9/16-18 thread size
• Sized for 0.375 inch (3/8 inch) ID, size 6 hoses
• Compliant with ISO 12151-5 fitting standards
• California Proposition 65 listed
• Packaged as 2 pieces per unit

Compatibility

Compatible with Parker hose series: 187 (TC, ST), 302, 304, 387 (TC, ST), 422, 424, 426, 436, 471TC, 471ST, 472TC, 482TC, 482ST, 487 (TC, ST), 722 (TC, ST), 787 (TC, ST), 797 (TC, ST), and 881 hoses.

Installation Notes

Installation should be performed by a qualified hydraulic technician. Depressurize and drain the hydraulic system completely before removing or installing any fittings. Inspect all mating threads and sealing surfaces for damage before assembly. Follow applicable fluid power standards and equipment OEM specifications for torque and assembly procedures.
