Parker KP17804 Steel Swivel Run Tee 5/8 in Flare

Product Description

The PARKER KP17804 is a steel swivel run tee fitting designed for flared tube connections in high-pressure fluid and pneumatic systems. It features a 37-degree flare angle on all three ends (flare x flare x flare) and accepts 5/8 inch tube OD. The swivel design allows rotational adjustment during installation without disturbing the tube or upstream connections. Rated to 5000 psi maximum working pressure and 500 degrees F, this fitting is suited for demanding hydraulic, refrigeration, and industrial plumbing applications. It is installed by licensed plumbers, hydraulic technicians, and HVAC-R mechanics working with flared metal tubing assemblies.

This fitting is used in high-pressure tubing runs where a branch tee connection is required and rotational alignment is a priority. The run tee configuration allows the primary flow path to continue straight through while the branch exits at 90 degrees. Typical installations include hydraulic lines, fuel systems, and industrial fluid transfer assemblies that operate at elevated temperatures and pressures. The 37-degree flare angle conforms to SAE and ISO flare standards, making it compatible with standard JIC-style flared tube components widely used in trade applications.

Key Features

• Swivel run tee allows rotational adjustment for easy alignment without re-cutting or re-flaring tube ends
• 37-degree flare angle on all three ports meets SAE and ISO flare specifications
• Rated to 5000 psi maximum working pressure for high-pressure system use
• Maximum working temperature of 500 degrees F suits high-heat environments
• All-steel construction provides durability in demanding hydraulic and industrial applications
• Conforms to ISO 8434-2, SAE 070432, and SAE J514 standards

Compatibility

Designed for use with 5/8 inch OD flared steel tubing in systems requiring 37-degree JIC-style flare connections conforming to SAE J514, SAE 070432, and ISO 8434-2 standards.

Installation Notes

Installation should be performed by a qualified plumber, hydraulic technician, or HVAC-R mechanic. Depressurize and isolate the system completely before disassembling any existing fittings or tubing connections. Use appropriate flaring tools to ensure a clean 37-degree flare seat before assembly, and inspect flare surfaces for burrs or deformation prior to torquing. Follow applicable system codes and the fitting manufacturer guidelines for proper assembly sequence when using swivel-style fittings.
