Parker KP103651 Hydraulic Hose 90 Degree Elbow Fitting

Product Description

The PARKER KP103651 is a 90-degree elbow hydraulic hose fitting machined from steel for use in hydraulic fluid conveyance systems. It connects an 8 mm hose to a 1-14 straight thread port, redirecting flow at a right angle to route hose assemblies around obstructions or into tight access points. The 13/32-inch hose inside diameter matches standard hydraulic hose specifications for this size class. Licensed hydraulic technicians and industrial mechanics install this fitting as part of hose assembly fabrication or field repair on hydraulic circuits across mobile, stationary, and industrial equipment.

This elbow fitting is used wherever a 90-degree change in hose direction is required in a hydraulic circuit. Typical applications include mobile equipment such as excavators, loaders, and agricultural machinery, as well as stationary hydraulic power units and industrial press systems. The 1-14 thread size is a common straight thread specification found on hydraulic cylinders, valves, pumps, and manifold ports in both OEM and aftermarket hydraulic systems.

Key Features

• 90-degree elbow configuration routes hose around obstructions without bending the hose itself
• Steel construction provides strength and durability in high-pressure hydraulic service
• 8 mm hose size with 13/32-inch inside diameter for precise hose-to-fitting compatibility
• 1-14 straight thread port connection for secure, leak-resistant assembly
• Compact design suits confined installation spaces in mobile and industrial equipment

Compatibility

Designed as an OEM-style replacement or assembly component for hydraulic hose systems requiring an 8 mm hose size with a 1-14 straight thread port connection and a 90-degree elbow configuration.

Installation Notes

Installation should be performed by a qualified hydraulic technician or mechanic. Depressurize and isolate the hydraulic circuit fully before removing or installing any hose fitting. Inspect the mating port threads and sealing surfaces for damage before assembly. Follow applicable system specifications for thread engagement and ensure proper torque using calibrated tooling per the equipment manufacturer's guidelines.
