Parker Hannifin MZK-45E14-HNBR ZoomLock MAX 45-Degree Elbow

Product Description

The Parker Hannifin MZK-45E14-HNBR is a 7/8 inches 45-degree elbow designed for secure connections in air conditioning and refrigeration systems. This fitting allows for leak-free connections without using gas or flames. With a pressure rating of up to 700 psi, it simplifies installation and enhances safety.

• No need for gas or flame during installation
• Flexible solutions for installation
• Safe operations without fire hazards

Product Highlights

The Parker Hannifin ZoomLock MAX fitting ensures a secure connection for refrigerant lines while minimizing installation risks.

Product Information

Standard Information

• Brand: Parker Hannifin
• Model Number: MZK-45E14-HNBR

Technical Specifications

• Size: 7/8 inches
• Material: Copper
• Min Temp: -40 degrees F
• Max Temp: 284 degrees F
• Outlet Connection Size: 7/8 inches
• Fitting Type: 45 Degree Elbow
• Inlet Connection Size: 7/8 inches
• Minimum Burst Pressure: 2100 psi
• Maximum Operating Temperature: 250 degrees F
• Minimum Operating Temperature: -40 degrees F
• Maximum Operating Pressure: 700 psi
• O-Ring Material: HNBR
• Refrigerant Types: Compatible with various refrigerants including 134A, 410A, and more.
• Connection Type: Press/Press
• Material Construction: Copper
• Pressure Rating: 700 psi
• Temperature Rating: -40 to 250 degrees F
• Additional Information: HNBR O-ring, 2100 psi Minimum Burst Pressure Rating
