PARKER HANNIFIN D165 Compact Electric Hose Crimper

Product Description

The PARKER HANNIFIN D165 is an electric hose crimper used to form secure connections in hydraulic hose assemblies. This crimper provides a crimping force of sixty-two tons, making it suitable for various hose types. It can handle two-wire and four-spiral hoses up to one and one-fourth inches in diameter, as well as six-spiral hoses up to one inch. The adjustable micrometer system allows for precise control over crimp diameters, ensuring accuracy in each application. Its open design features a two-piece slide-in die set and a removable pusher, which enhances visibility during fitting alignment before crimping. An automatic stop switch promotes operational efficiency by ensuring the crimp cycle is completed correctly.

• Delivers a crimping force of sixty-two tons for hydraulic hose assemblies.
• Equipped with a micro-crimp adjuster for precise and consistent crimp diameters.
• Open design with a two-piece slide-in die set for accurate fitting positioning.

Product Highlights

Product Information

Standard Information

• Brand: PARKER HANNIFIN
• Product Type: Crimper

Technical Specifications

• Crimping Force: 62 tons
• Max Hydraulic Hose Capacity (2 Wire): 1-1/4 inches
• Max Hydraulic Hose Capacity (4 Spiral): 1-1/4 inches
• Max Hydraulic Hose Capacity (6 Spiral): 1 inch
• Standard Power: 1 HP / 110V / 1 Phase
• Control System: Adjustable Micrometer
• Pump Type: Electric
• Weight: 154 lbs
• Dimensions: 22-1/2 x 13 x 22-1/2 inches
