Parker Hannifin 13943-8-6 Jic Swivel 90 Elbow Hose Fitting

Product Description

The PARKER HANNIFIN 13943-8-6 is a short drop female JIC swivel 90-degree elbow fitting designed for hydraulic hose assemblies. Constructed from steel, it connects to hoses with a 0.375-inch (3/8-inch) inside diameter and uses a 3/4-16 inch threaded connection. The swivel design allows for rotational adjustment during assembly, reducing hose twist and simplifying routing in tight installations. This fitting is part of Parker Series 43 and is intended for use by hydraulic system technicians, mobile equipment mechanics, and industrial maintenance professionals working with medium- to high-pressure hydraulic lines.

This fitting is suited for hydraulic hose assemblies on mobile equipment, agricultural machinery, construction equipment, and industrial fluid power systems. It is rated for use with a broad range of Parker hose series, making it a versatile component for shops that stock and fabricate hydraulic lines. The 90-degree elbow configuration is commonly used where hose routing must change direction near a port or bulkhead with limited clearance. Sold individually with a minimum order quantity of one.

Key Features

• Short drop female JIC swivel 90-degree elbow configuration for angled port connections
• Steel construction for durability in hydraulic service environments
• 0.375-inch (3/8-inch) hose inside diameter, Hose Size 6
• 3/4-16 inch threaded connection, female JIC shaft type
• Swivel design reduces hose twist during assembly and final torque
• Compliant with ISO 12151-5 and California Proposition 65 requirements

Compatibility

Designed for use with Parker hose series 187 TC ST, 302, 304, 387 TC ST, 422, 424, 426, 436, 471TC, 471ST, 472TC, 482TC, 482ST, 487 TC ST, 722 TC ST, 787 TC ST, 797 TC ST, and 881 hoses.

Installation Notes

Installation should be performed by a qualified hydraulic technician familiar with JIC threaded fittings and hydraulic hose assembly practices. Depressurize and isolate the hydraulic circuit completely before removing or installing any fittings. Use appropriate wrenches on the hex flats only — do not grip the swivel body — and confirm thread engagement is clean and free of damage before final assembly. Follow applicable fluid power safety standards and equipment manufacturer specifications for system pressure ratings.
