Parker H35VXBG023D Solenoid Valve Bspp 120V Pneumatic

Product Description

The PARKER H35VXBG023D is a normally closed solenoid valve designed for pneumatic system applications. It features a BSPP-threaded body machined from aluminum with a nitrile seal, and operates on 120 volts AC. In its de-energized state the valve remains closed, blocking flow until the solenoid coil is energized. With a Cv factor of 5.0, it delivers reliable flow capacity for a range of pneumatic control circuits. The unit carries cCSAus approval and meets ISO 1179 specifications, making it suitable for industrial and commercial pneumatic installations. Licensed HVAC and industrial service technicians are the primary installers of this type of directional control valve.

This valve is suited for pneumatic control applications in commercial and industrial environments where BSPP manifold and subbase port connections are required. It is rated for operation across a temperature range of 5 degrees F to 120 degrees F, making it appropriate for both indoor and controlled outdoor pneumatic circuits. The BSPP thread standard and subbase port compatibility align with ISO 1179 manifold configurations commonly found in automated process and fluid-power systems. The IP65 enclosure rating provides protection against dust ingress and low-pressure water jets, adding durability in demanding service environments.

Key Features

• Normally closed operation — valve blocks flow until coil is energized
• BSPP thread standard with ISO 1179 manifold and subbase port compliance
• Aluminum body construction for reduced weight in pneumatic assemblies
• Nitrile seal material compatible with standard compressed-air service
• IP65 enclosure rating — dust-tight with protection against water jets
• cCSAus approved for use in North American installations
• Cv factor of 5.0 for consistent flow performance in pneumatic circuits

Compatibility

Designed for use with BSPP manifold and subbase port systems meeting ISO 1179 specifications in pneumatic control applications.

Installation Notes

Installation should be performed by a qualified technician familiar with pneumatic control systems and applicable codes. De-energize and depressurize the pneumatic circuit fully before removing or installing any solenoid valve. Verify that supply voltage matches the 120 volts AC coil rating before energizing. Follow the equipment manufacturer's torque and port-sealing guidelines for BSPP threaded connections to avoid leaks or thread damage.
