Parker H25VXBG023D Solenoid Valve 4-way 3-position 120V

Product Description

The PARKER H25VXBG023D is a 4-way, 3-position solenoid valve designed for pneumatic system control. It operates in the normally closed state when de-energized, meaning air flow is blocked until the solenoid is actuated. The valve is rated at 120 volts AC and carries a Cv factor of 2.8, making it suited for moderate-flow pneumatic circuit applications. The aluminum body keeps weight manageable at 5 pounds, while the nitrile seals provide reliable resistance to common pneumatic system contaminants and lubricants. Pneumatic technicians and industrial maintenance professionals are the primary installers of this type of directional control valve.

This valve is intended for pneumatic directional control circuits where a 4-way, 3-position configuration is required. The 3-position design allows for mid-position flow control between actuator ports, which is common in applications requiring a held or exhaust center condition. Typical installations include industrial automation systems, pneumatic cylinder circuits, and process control equipment operating on 120 volts AC power.

Key Features

• 4-way, 3-position directional control for pneumatic circuits
• Normally closed unactuated state blocks flow when de-energized
• 120 volts AC coil voltage for standard industrial power compatibility
• Cv factor of 2.8 supports moderate pneumatic flow rates
• Aluminum body construction for reduced weight
• Nitrile seals for resistance to common pneumatic lubricants and contaminants

Compatibility

Designed as an OEM-style directional control valve for pneumatic systems requiring a 4-way, 3-position, normally closed configuration at 120 volts AC.

Installation Notes

Installation should be performed by a qualified pneumatic or industrial maintenance technician. Depressurize the pneumatic circuit and de-energize all electrical power before removing or installing the valve. Verify that the system supply voltage matches the 120 volts AC coil rating before energizing. Follow applicable NFPA and local codes for pneumatic and electrical installations.
