Parker H22VXBG023D 4-way 2-position Solenoid Valve

Product Description

The PARKER H22VXBG023D is a 4-way, 2-position solenoid valve designed for pneumatic control applications. It operates in the normally open state through ports 1 and 2 and actuates on a 120-volt AC signal to shift flow direction. The body is constructed from aluminum and uses a nitrile seal, making it a durable, corrosion-resistant choice for industrial pneumatic circuits. With a Cv rating of 3.0, it delivers adequate flow capacity for a range of actuator and directional control tasks. Licensed pneumatic technicians and industrial maintenance professionals are the primary installers of this valve in field and panel-mount configurations.

This valve is suited for pneumatic directional control in industrial and commercial automation environments. It is commonly installed in manifold or subbase configurations that conform to ISO 1179 specifications and BSPP manifold port standards. Applications include cylinder actuation, air motor reversing, and multi-circuit pneumatic panel assemblies. The operating temperature range runs from 5 degrees F to 120 degrees F, keeping it viable in both outdoor enclosures and temperature-controlled plant floors. The IP65 rating provides protection against dust ingress and low-pressure water jets.

Key Features

• 4-way, 2-position directional control with normally open state through ports 1 and 2
• 120-volt AC solenoid actuation for standard industrial control voltage compatibility
• Cv rating of 3.0 supports adequate pneumatic flow for single and double-acting cylinder circuits
• Aluminum body construction reduces weight while maintaining structural integrity
• Nitrile seals provide reliable performance across the full rated temperature range
• IP65 rated for dust-tight and splash-resistant installation environments
• cCSAus approved and compliant with ISO 1179 specifications for international interchangeability

Compatibility

Designed for use with BSPP manifold and subbase port assemblies that meet ISO 1179 specifications. Compatible with standard pneumatic control systems operating on 120-volt AC circuits in industrial and commercial automation applications.

Installation Notes

Installation should be performed by a qualified pneumatic or industrial maintenance technician. De-energize the control circuit and depressurize the pneumatic system fully before removing or installing the valve. Verify BSPP thread engagement and torque to fitting manufacturer specifications using appropriate thread sealant compatible with nitrile seals. Confirm supply voltage matches the 120-volt AC solenoid rating before energizing.
