Parker H15VXBG023D Solenoid Valve Bspp Normally Closed

Product Description

The PARKER H15VXBG023D is a normally closed solenoid valve designed for pneumatic system applications. When de-energized, the valve remains closed and seals the flow path until 120 volts AC is applied to the coil, at which point the valve actuates and allows flow. The aluminum body keeps weight low while providing structural durability in industrial environments. A nitrile seal provides reliable shutoff across a wide operating temperature range of 5 degrees F to 120 degrees F. With a Cv factor of 1.2, this valve is sized for moderate pneumatic flow requirements. Installation is typically performed by instrumentation technicians or industrial maintenance professionals familiar with pneumatic control systems.

The H15VXBG023D is intended for pneumatic control applications where a normally closed, electrically actuated shutoff or directional control point is needed. BSPP threading conforms to ISO 1179 specifications, making this valve compatible with metric-threaded pneumatic manifolds and subbase port assemblies that follow BSPP manifold and subbase port standards. The valve carries a cCSAus approval and an IP65 ingress protection rating, making it suitable for environments where dust and water spray are a concern. Typical use cases include automated pneumatic circuits in manufacturing, process control panels, and similar industrial installations.

Key Features

• Normally closed operation — valve is sealed when coil is de-energized
• 120 volts AC coil voltage for compatibility with standard industrial control circuits
• BSPP threaded ports conforming to ISO 1179 specifications
• Aluminum body construction for lightweight, durable service
• Nitrile seal material suitable for a wide range of pneumatic media
• IP65 rated for protection against dust ingress and low-pressure water jets
• cCSAus approved for use in North American and Canadian installations

Compatibility

Designed for use with BSPP manifold and subbase port assemblies meeting ISO 1179 specifications in pneumatic control systems.

Installation Notes

Installation should be performed by a qualified instrumentation or industrial maintenance technician. De-energize and depressurize the pneumatic system fully before removing or installing the valve. Verify that the supply voltage matches the 120 volts AC coil rating before making electrical connections. BSPP threads require appropriate thread sealant or sealing compound rated for pneumatic service — do not overtighten, as aluminum bodies are susceptible to thread damage.
