Parker gbw.un383412030b Insulated Suction Line Set 30 Ft

Product Description

The PARKER gbw.un383412030b is a pre-insulated suction line set designed for residential and light commercial HVAC refrigerant line installations. This suction-line-only assembly includes a 3/4-inch suction line and a 3/8-inch liquid line, both insulated to 1/2-inch thickness using a black polyethylene foam jacket over copper tubing. The 30-foot length suits most standard split-system installations where the air handler and condensing unit are separated by a typical run. The copper meets ASTM B280 UNS C10200 standards, and the insulation conforms to ASTM C1427-07, ensuring compliance with material quality requirements commonly specified on commercial projects.

This insulated line set is suited for split-system air conditioning and heat pump installations in residential and light commercial applications. The pre-insulated design reduces field labor by eliminating the need to apply separate foam insulation tape or sleeves on the suction line after routing. It is appropriate for new installations and replacement runs where the existing lineset has been damaged or undersized. The black polyethylene jacket is UV-resistant for short exterior runs, and the 30-foot length accommodates most standard equipment placements without field splicing.

Key Features

• 3/4-inch suction line and 3/8-inch liquid line in a single pre-insulated assembly
• 1/2-inch polyethylene foam insulation thickness reduces condensation and heat gain on the suction line
• Copper tubing meets ASTM B280 UNS C10200 material standard for refrigerant-grade quality
• Insulation conforms to ASTM C1427-07 material standard
• Temperature rating of -94 to 250 degrees F suits refrigerant operating conditions
• Domestically manufactured

Compatibility

Designed as an OEM-style replacement or new-installation line set for split-system air conditioning and heat pump equipment requiring a 3/4-inch suction line and 3/8-inch liquid line connection with pre-applied insulation.

Installation Notes

Installation should be performed by a licensed HVAC technician with EPA Section 608 certification, as the line set will be connected to a refrigerant circuit. The system must be fully recovered and de-pressurized before cutting or connecting copper lines. Standard refrigeration-grade flaring or brazing tools are used to make connections at the indoor and outdoor units. Secure the line set at regular intervals per local mechanical code requirements to prevent vibration wear on the insulation jacket.

Technical Specifications

• Length: 30 ft
• Suction Line Size: 3/4 inches
• Liquid Line Size: 3/8 inches
• Insulation Thickness: 1/2 inches
• Temperature Rating: -94 to 250 degrees F
• Material: Copper/Polyethylene
• Material Standard: ASTM B280 UNS C10200, ASTM C1427-07
• Color: Black
• Country of Origin: Domestic

Standard Information

• Brand: PARKER
• Manufacturer Part Number: gbw.un383412030b
