Parker FAME-46 Compression Female Adapter Elbow 1/4 in

Product Description

The PARKER FAME-46 is a compression tube female adapter elbow designed for 1/4-inch outside diameter tubing. It provides a 90-degree directional change at a female threaded connection point using a compression-style grip fitting. The body and grip components are made from Perfluoroalkoxy (PFA) and Polytetrafluoroethylene (PTFE), both of which offer excellent chemical resistance and low friction properties. This fitting is well suited for fluid handling, pneumatic, and instrumentation lines where corrosion resistance and material compatibility with aggressive media are required. Licensed plumbers, HVAC technicians, and instrumentation specialists are the typical installers.

This fitting is used in applications where a tube must transition to a female threaded port at an angled orientation. PFA and PTFE construction makes it appropriate for systems handling corrosive chemicals, high-purity fluids, or environments where metal fittings would be incompatible. Common installation scenarios include laboratory instrumentation lines, chemical process equipment, and specialty HVAC or refrigeration tubing runs where plastic compression fittings are specified.

Key Features

• Compression-style connection for 1/4-inch OD tubing — no soldering or flaring required
• 90-degree female adapter elbow configuration for directional routing at a threaded port
• PFA and PTFE construction provides strong chemical resistance and non-stick surface properties
• Plastic grip type for lightweight, corrosion-free clamping
• Sold individually — single-piece package quantity

Compatibility

Designed as an OEM-style compression fitting for 1/4-inch OD tubing systems requiring a female adapter elbow in PFA or PTFE material.

Installation Notes

Installation is performed by licensed plumbers or instrumentation technicians familiar with compression-style plastic fittings. Before installation, shut off all fluid or gas flow and depressurize the line completely. Hand-tighten compression fittings first, then apply only the minimal additional turn needed to seat the compression ring — overtightening plastic compression fittings can crack the body or distort the ferrule. Verify thread engagement and fitting alignment before restoring system pressure.
