Parker F1600B Hydraulic Control Valve 1 in Npt 40 Gpm 500 Psi

Product Description

The PARKER F1600B is a brass hydraulic control valve designed to regulate flow in hydraulic systems. It features a 1-inch NPT threaded inlet with an 11-1/2 thread size and handles flow rates up to 40 GPM at a maximum working pressure of 500 psi. The knob handle allows direct manual control of flow. At 5 inches overall length and 5.1 pounds, this valve is built for durability in demanding hydraulic circuits. Nitrile seals provide resistance to petroleum-based hydraulic fluids. Licensed hydraulic technicians and pipefitters are the typical installers.

The F1600B is suited for use in industrial and mobile hydraulic systems where manual flow control is required. Its brass construction makes it appropriate for applications where corrosion resistance and machinability are priorities. The 1-inch NPT connection integrates with standard hydraulic plumbing runs in both stationary and mobile equipment installations. It is packaged as a single unit and requires no additional hardware for connection to NPT-threaded hydraulic lines.

Key Features

• 40 GPM maximum flow rate for medium-duty hydraulic circuits
• 500 psi maximum working pressure rating
• 1-inch NPT inlet with 11-1/2 thread standard for compatibility with standard hydraulic fittings
• Brass body construction for corrosion resistance
• Nitrile seals compatible with petroleum-based hydraulic fluids
• Knob handle for direct, tactile manual flow adjustment
• Compact 5-inch overall length for space-constrained installations

Compatibility

Designed as an OEM-style replacement or service valve for hydraulic systems using 1-inch NPT connections rated up to 500 psi and 40 GPM.

Installation Notes

Installation should be performed by a licensed hydraulic technician or pipefitter familiar with hydraulic system service procedures. Depressurize and de-energize the hydraulic system completely before removing any existing valve or fitting. Apply appropriate thread sealant compatible with hydraulic fluid to the NPT threads before installation. Do not exceed the rated 500 psi working pressure or 40 GPM flow rate during operation.
