Parker F1200B Hydraulic Control Valve 25 Gpm 2000 Psi 3/4 Npt

Product Description

The PARKER F1200B is a hydraulic control valve designed for fluid power systems requiring precise flow management at high working pressures. Built with a brass body and nitrile seals, this valve handles up to 25 GPM and a maximum working pressure of 2,000 psi. The 3/4-14 NPT threaded inlet and outlet allow straightforward integration into standard hydraulic circuits. A knob-style handle provides manual flow control in applications where operator adjustment is needed at the valve. At 3.88 inches overall length, the compact form factor suits installations where space is limited. Hydraulic system technicians and fluid power specialists are the primary installers of this type of valve.

This valve is suited for industrial and mobile hydraulic applications where a manually adjustable, inline flow control point is required. Typical installations include hydraulic power units, machine tool circuits, and mobile equipment hydraulic systems operating within the 25 GPM and 2,000 psi rated parameters. The brass body makes it appropriate for systems where corrosion resistance to hydraulic fluid and compatible media is a priority. It is sold individually and is intended for professional hydraulic system installation and service.

Key Features

• 25 GPM maximum flow rate for high-demand hydraulic circuits
• 2,000 psi maximum working pressure rating
• 3/4-14 NPT thread for compatibility with standard hydraulic fittings
• Brass body construction for corrosion resistance
• Nitrile seals suitable for use with common hydraulic fluids
• Knob handle provides manual, tool-free flow adjustment

Compatibility

Designed as an OEM-style replacement or service valve for hydraulic systems requiring a 3/4-14 NPT inline control valve rated to 25 GPM and 2,000 psi maximum working pressure.

Installation Notes

Installation should be performed by a qualified hydraulic system technician. Depressurize and de-energize the hydraulic circuit fully before removing or installing any valve. Apply appropriate thread sealant to NPT connections per system requirements, and torque fittings according to the fitting manufacturer specifications. Confirm flow direction and pressure rating compatibility with the existing system before placing the valve in service.
