Parker DT-1250-MOMF-5 Hydraulic Check Valve 80 Gpm

Product Description

The PARKER DT-1250-MOMF-5 is a hydraulic control check valve designed to allow flow in one direction while preventing backflow in hydraulic circuits. Built from steel with metal seals, it is rated for a maximum working pressure of 4000 psi and a maximum flow rate of 80 GPM. The compact body measures 2.75 inches in overall length, 1.88 inches in width, and 1.88 inches in height, making it suitable for installations where space is limited. The inlet connection is a 1-5/8-12 thread with a Male ORB x Male JIC thread standard. This valve is installed by hydraulic system technicians on mobile equipment, industrial machinery, and fluid power systems.

The DT-1250-MOMF-5 is suited for hydraulic circuits in industrial and mobile applications where controlled unidirectional flow and backflow prevention are required. Its steel construction and metal seal make it appropriate for high-pressure hydraulic systems operating in demanding environments. It is a direct-installation component in systems that require a reliable, compact check valve at a 1-5/8-12 Male ORB x Male JIC interface. Licensed hydraulic system technicians and fluid power specialists are the typical installers.

Key Features

• Rated to 4000 psi maximum working pressure for demanding hydraulic applications
• Handles flow rates up to 80 GPM
• Steel body construction with metal seals for durability in high-pressure environments
• 1-5/8-12 inlet with Male ORB x Male JIC thread standard for secure hydraulic connections
• Compact footprint at 2.75 inches length and 1.88 inches height and width

Compatibility

Designed as an OEM-style replacement or direct-fit component for hydraulic circuits requiring a 1-5/8-12 Male ORB x Male JIC check valve rated to 4000 psi and 80 GPM.

Installation Notes

Installation should be performed by a qualified hydraulic technician or fluid power specialist. Depressurize the hydraulic system completely and relieve all stored pressure before removing or installing any hydraulic valve. Ensure thread compatibility and use appropriate hydraulic fittings and sealants as required by the system design. Follow all applicable fluid power safety standards and equipment manufacturer guidelines during installation.
