Parker CV-750-MFMF-5 Hydraulic Check Valve 65 Gpm

Product Description

The PARKER CV-750-MFMF-5 is a hydraulic control check valve designed to allow fluid flow in one direction while preventing backflow in hydraulic systems. Built with a steel body and nitrile seals, it handles a maximum working pressure of 3000 psi and a maximum flow rate of 65 GPM. The inlet and outlet are both 1-1/16-12 Male JIC threaded connections, making it a compact inline component suited for high-pressure hydraulic circuits. Licensed hydraulic system technicians and fluid power specialists typically install and service this valve in industrial and mobile hydraulic applications.

This check valve is used in hydraulic systems requiring reliable one-directional flow control at elevated pressures. Its Male JIC thread configuration on both ports simplifies integration into existing JIC-plumbed hydraulic lines. Typical installations include mobile equipment, industrial machinery, and hydraulic power units where backflow prevention is critical to system integrity and component protection. The compact overall dimensions make it suitable for installations where space is limited.

Key Features

• Maximum working pressure of 3000 psi for high-pressure hydraulic circuits
• Maximum flow rate of 65 GPM to support demanding hydraulic applications
• 1-1/16-12 Male JIC threaded inlet and outlet for straightforward line integration
• Steel body construction for durability in demanding hydraulic environments
• Nitrile seals compatible with standard petroleum-based hydraulic fluids
• Compact form factor at 2.75 inches overall length and 1.38 inches overall height and width

Compatibility

Designed as an OEM-style replacement or new-installation check valve for hydraulic systems plumbed with 1-1/16-12 Male JIC fittings operating within a 3000 psi working pressure range.

Installation Notes

Installation should be performed by a qualified hydraulic technician or fluid power specialist. Always depressurize and de-energize the hydraulic system completely before removing or installing any valve. Verify that the system fluid type is compatible with nitrile seals prior to installation. Follow applicable fluid power standards and equipment manufacturer guidelines for proper torque and fitting procedures.
