Parker CV-500-MOMF-5 Hydraulic Check Valve 50 Gpm

Product Description

The PARKER CV-500-MOMF-5 is a hydraulic control check valve designed to allow flow in one direction while preventing backflow in hydraulic systems. Built from a steel body with nitrile seals, it handles up to 50 GPM and a maximum working pressure of 3,000 psi. The valve uses a Male ORB x Male JIC thread configuration with a 3/4-16 inlet and 3/4-16 outlet, making it a compact, inline solution for mobile and industrial hydraulic circuits. At 0.432 pounds and just 2.22 inches in overall length, it fits into tight plumbing runs without adding significant bulk to the assembly.

This check valve is suited for mobile equipment, industrial hydraulic power units, and other applications where preventing reverse flow is critical to system integrity. Typical installation scenarios include hydraulic cylinders, motor circuits, and pressure-line protection on equipment serviced by hydraulic technicians and fluid power specialists. The Male ORB x Male JIC thread standard is common across a wide range of hydraulic component plumbing configurations in both agricultural and construction equipment.

Key Features

• Steel body construction for durability in high-pressure hydraulic environments
• Nitrile seals compatible with standard petroleum-based hydraulic fluids
• 50 GPM maximum flow rate for medium-duty hydraulic circuits
• 3,000 psi maximum working pressure rating
• 3/4-16 Male ORB x Male JIC thread configuration for direct inline installation
• Compact design at 2.22 inches overall length and 1 inch overall height and width

Compatibility

Designed as an OEM-style replacement or direct-fit component for hydraulic systems requiring a 3/4-16 Male ORB x Male JIC inline check valve rated to 3,000 psi and 50 GPM.

Installation Notes

Installation should be performed by a qualified hydraulic technician or fluid power specialist. Depressurize and fully de-energize the hydraulic system before removing any fittings or installing this valve. Ensure all mating threads are clean and undamaged before assembly, and use appropriate thread sealant or O-ring as required by the fitting type. Follow applicable industry standards and equipment manufacturer guidelines for hydraulic plumbing and pressure-system service.
