Parker CV-1000-MFMF-5 Hydraulic Check Valve 100 Gpm

Product Description

The PARKER CV-1000-MFMF-5 is a hydraulic control check valve designed to allow one-directional flow and prevent backflow in hydraulic circuit lines. Rated for a maximum working pressure of 3,000 psi and a maximum flow rate of 100 GPM, this valve is built for demanding industrial and mobile hydraulic applications. The body is constructed from steel and uses Nitrile seals for reliable fluid compatibility. Both the inlet and outlet are 1-5/16-12 Male JIC thread fittings, making installation straightforward in systems already plumbed with JIC connections. Hydraulic technicians and fluid power specialists are the typical installers of this component.

This check valve is suited for use in hydraulic power units, mobile equipment circuits, and industrial machinery where backflow prevention is required at moderate-to-high operating pressures. Its compact overall dimensions of 3.31 inches in length, 1.62 inches in width, and 1.62 inches in height allow it to fit in tight manifold or inline plumbing configurations. The Male JIC thread standard on both ports makes it compatible with standard JIC hydraulic line assemblies common in agricultural, construction, and industrial equipment.

Key Features

• Prevents backflow in hydraulic circuits with a check-valve design rated to 3,000 psi maximum working pressure
• Handles flow rates up to 100 GPM for high-demand hydraulic applications
• 1-5/16-12 Male JIC threaded inlet and outlet for straightforward inline installation
• Steel body construction for durability under high-pressure hydraulic service
• Nitrile seals provide broad compatibility with standard petroleum-based hydraulic fluids
• Compact footprint at 3.31 x 1.62 x 1.62 inches and 1.497 pounds for easy integration

Compatibility

Designed as an OEM-style inline check valve for hydraulic systems utilizing 1-5/16-12 Male JIC threaded connections and operating within 100 GPM flow and 3,000 psi pressure ratings.

Installation Notes

Installation should be performed by a qualified hydraulic technician or fluid power specialist. Depressurize and fully isolate the hydraulic circuit before removing or installing any valves. Use the appropriate JIC fitting torque procedure per the fitting manufacturer specifications and confirm all connections are leak-free before returning the system to service. Verify that system fluid type is compatible with Nitrile seals prior to installation.
