Parker BVHP16NSS1N Ball Valve 1 Inch Fnpt 6000 Psi

Product Description

The PARKER BVHP16NSS1N is a standard manual ball valve designed for high-pressure fluid and gas control applications. Built with a carbon steel body and carbon steel trim, this valve handles up to 6000 psi working pressure, making it suitable for demanding industrial and trade service environments. A Delrin seal provides reliable shutoff performance. The lever handle allows for quick quarter-turn operation, giving technicians fast on/off control in tight service conditions. Licensed plumbers, pipefitters, and industrial mechanics are the typical installers for this type of valve.

This valve is suited for high-pressure piping systems in commercial and industrial settings where a robust, lever-operated ball valve is required. The 1-inch female NPT inlet and outlet connections make it compatible with standard threaded pipe assemblies. Applications include hydraulic lines, compressed air systems, and process piping where a rated working pressure of 6000 psi is a required specification. Always verify that the seal material is chemically compatible with the media being controlled before installation.

Key Features

• Maximum working pressure of 6000 psi (414 bar) for high-pressure service
• Carbon steel body and trim for strength in demanding environments
• Delrin seal material for reliable shutoff and wear resistance
• 1-inch FNPT x FNPT end connections for standard threaded pipe assembly
• Lever handle enables fast quarter-turn on/off operation
• California Proposition 65 listed

Compatibility

Designed as a standard OEM-style replacement or new-installation ball valve for 1-inch FNPT threaded piping systems rated to high-pressure service.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable local codes and the International Plumbing Code (IPC). Depressurize and isolate the system completely before removing or installing this valve. Apply thread sealant or PTFE tape appropriate for the service media on all NPT threaded connections. Verify flow direction and confirm seal compatibility with the system fluid before returning the line to service.
