Parker BVHP12NSS1N Ball Valve 3/4 Inch Fnpt 6000 Psi

Product Description

The PARKER BVHP12NSS1N is a standard manual ball valve designed for high-pressure fluid control in demanding industrial and mechanical systems. Built with a carbon steel body and carbon steel trim, this valve is rated to 6000 psi working pressure, making it suitable for hydraulic lines, compressed gas systems, and other high-pressure piping applications. The lever handle allows for quick quarter-turn shutoff. A Delrin seal provides reliable seating performance across a range of media. Licensed trades and qualified technicians install this valve in systems where positive shutoff and pressure integrity are critical requirements.

This valve is configured with female NPT connections on both ends, accepting 3/4 inch pipe. It is suited for use in industrial fluid power circuits, hydraulic control panels, compressed air distribution, and similar high-pressure piping systems. The FNPT x FNPT end connections allow straightforward integration into threaded piping assemblies without the need for additional adapters in standard configurations. Both light commercial and heavy industrial installations are common applications for this valve size and pressure rating.

Key Features

• 6000 psi maximum working pressure rating for high-pressure system compatibility
• Carbon steel body and trim for durability in industrial environments
• Delrin seal material provides reliable shutoff performance
• FNPT x FNPT end connections for direct threaded pipe installation on 3/4 inch pipe
• Lever handle design enables fast quarter-turn open and close operation

Compatibility

Designed as an OEM-style replacement or direct-install standard ball valve for 3/4 inch threaded piping systems requiring high-pressure shutoff capability up to 6000 psi.

Installation Notes

Installation of this valve should be performed by a licensed pipefitter, plumber, or qualified mechanical technician familiar with high-pressure piping systems. Depressurize and isolate the line completely before removing or installing any valve. Apply appropriate thread sealant to the FNPT connections per manufacturer guidelines and relevant plumbing or mechanical codes. Do not exceed the rated working pressure of 6000 psi in service.
