Parker BVHP08NSS1N Ball Valve 1/2 Inch Fnpt 6000 Psi

Product Description

The PARKER BVHP08NSS1N is a standard manual ball valve designed for high-pressure fluid control in industrial and mechanical systems. It features a 1/2 inch FNPT x FNPT end connection and a carbon steel body rated to 6000 psi working pressure. The lever handle allows for quick quarter-turn shutoff, making it well suited for hydraulic lines, pneumatic circuits, and other high-pressure piping applications. Delrin seal material provides reliable seating performance across a broad range of service conditions. This valve is typically installed by licensed pipefitters, HVAC technicians, and industrial maintenance professionals.

This ball valve is intended for high-pressure service in industrial, mechanical, and process piping systems. The 1/2 inch pipe size and FNPT x FNPT end connections make it compatible with standard threaded pipe configurations commonly found in hydraulic power units, compressed air systems, and fluid transfer lines. It is suited for both new installations and replacement service where a threaded, full-manual shutoff valve is required.

Key Features

• 6000 psi maximum working pressure rating for demanding high-pressure service
• Carbon steel body and trim for durability in industrial environments
• 1/2 inch FNPT x FNPT connections for standard threaded pipe fitment
• Lever handle enables fast quarter-turn open and close operation
• Delrin seat and seal material for consistent shutoff performance

Compatibility

Designed as an OEM-style replacement or new-installation manual ball valve for 1/2 inch threaded pipe systems requiring high-pressure shutoff capability.

Installation Notes

Installation should be performed by a qualified pipefitter or licensed mechanic in accordance with applicable piping codes. Depressurize and isolate the line completely before removing or installing any valve. Apply thread sealant appropriate for the service fluid and pressure rating to all FNPT connections. Do not exceed the rated working pressure of 6000 psi.
